Inclusive of PG23DNA grille
PC-ARF hardwired controller quoted as standard.
Infra-red and simplified controllers are available.
*Call Logicool on 01283 218277 regarding R22 replace on Utopia ES systems.
Model Reference | System Type | UK Cooling (kW) | UK Heating (kW) | Pipe (m) | EuP Lot 10 Energy Rating | Fuse (Amps) | Pipe Gas | Pipe Liquid | R22 replace? | Power Supply |
|
---|---|---|---|---|---|---|---|---|---|---|---|
Indoor Unit | SCOP** | SEER** | |||||||||
RCD-2FSN2 | IVX-P | 5.30 | 6.40 | 50 | TBC | TBC | 16 | 1/2 | 1/4 | Yes | Single |
RCD-2.5FSN2 | IVX-P | 5.80 | 7.20 | 50 | TBC | TBC | 20 | 1/2 | 1/4 | Yes | Single |
RCD-3FSN2 | ES | 7.34 | 7.43 | 30 | 3.40 | 3.78 | 25 | 5/8 | 3/8 | Yes* | Single |
RCD-3FSN2 | IVX-C | 7.60 | 7.90 | 50 | TBC | TBC | 25 | 5/8 | 3/8 | Yes | Single |
RCD-3FSN2 | IVX-P | 7.60 | 9.80 | 50 | TBC | TBC | 20 | 5/8 | 3/8 | Yes | Single |
RCD-4FSN2 | ES | 10.45 | 10.85 | 50 | 3.40 | 4.27 | 32 | 5/8 | 3/8 | Yes* | Single |
RCD-4FSN2 | IVX-C | 10.50 | 12.90 | 70 | TBC | TBC | 32 | 5/8 | 3/8 | Yes | Single |
RCD-4FSN2 | IVX-P | 10.50 | 12.90 | 75 | TBC | TBC | 32 | 5/8 | 3/8 | Yes | Single |
RCD-5FSN2 | ES | 12.93 | 13.95 | 50 | 3.09** | 2.80** | 32 | 5/8 | 3/8 | Yes* | Single |
RCD-5FSN2 | IVX-C | 13.00 | 14.10 | 75 | TBC | TBC | 32 | 5/8 | 3/8 | Yes | Single |
RCD-5FSN2 | IVX-P | 13.20 | 16.10 | 75 | TBC | TBC | 32 | 5/8 | 3/8 | Yes | Single |
RCD-4FSN2 | ES | 10.45 | 10.85 | 50 | 3.40 | 4.17 | 20 | 5/8 | 3/8 | Yes* | Three |
RCD-4FSN2 | IVX-C | 10.50 | 12.90 | 70 | TBC | TBC | 20 | 5/8 | 3/8 | Yes | Three |
RCD-4FSN2 | IVX-P | 10.50 | 12.90 | 75 | TBC | TBC | 16 | 5/8 | 3/8 | Yes | Three |
RCD-5FSN2 | ES | 12.93 | 13.95 | 50 | 3.09** | 2.80** | 20 | 5/8 | 3/8 | Yes* | Three |
RCD-5FSN2 | IVX-C | 13.00 | 14.10 | 75 | TBC | TBC | 20 | 5/8 | 3/8 | Yes | Three |
RCD-5FSN2 | IVX-P | 13.20 | 16.10 | 75 | TBC | TBC | 16 | 5/8 | 3/8 | Yes | Three |
POWER/WIRING:Power supply to both Indoor Unit and Outdoor Unit. It is also possible to supply power to outdoor unit only and run power to Indoor Unit from field supplied, fused terminal block. This must be separate to 2 Core data cable.
UK Conditions based on 22°C DB / 15°C WB Indoor , 30°C DB Ambient (Cooling) and 21°C DB, 0°C DB Ambient (Heating)
